Achieve your business goals with Tata Ultra T6, the intermediate light truck that’s designed for heavy profits. Whether you're making local deliveries or embarking on longer journeys, this vehicle is equipped to handle it all.

Navigate City Streets
with Ease

Achieve your business goals with Tata Ultra T6, the intermediate light truck that’s designed for heavy profits. Whether you're making local deliveries or embarking on longer journeys, this vehicle is equipped to handle it all.

Move ahead with the power to do more

  • <p>Emission Compliant Standard</p>

    Euro IV

    Emission Compliant Standard

  • <p>Capacity of 3300 cc</p>

    Engine

    Capacity of 3300 cc

  • <p>Max Torque of 390 Nm </p>

    Torque

    Max Torque of 390 Nm

  • <p>45%</p>

    Gradeability

    45%

ULTRA T.6
ULTRA T.6
ULTRA T.6
ULTRA T.6

ULTRA T.6

Equipped with a robust compression ignition engine, the Ultra T.6 delivers unmatched performance and reliability every single time. With a commanding maximum power output of 125 PS at 2600 rpm and an impressive torque of 390 Nm, this light pickup truck is engineered to conquer every road and challenge.

With the Tata G550 Synchromesh 6F + 1R gearbox, experience seamless gear transitions. The advanced braking system, featuring dual-circuit full-air S-cam brakes along with ABS and ESP, offers unparalleled stopping power and safety, even in the most challenging terrains. The fusion of parabolic and semi-elliptical leaf springs ensures stability and shock absorption, allowing you to traverse various landscapes with ease.

3.3L NG CR E-IV Engine
Maximum Power of 125 Ps
Rugged Gearbox Tata G550 6F+1R with Cable Shift Mechanism
Dual Circuit Full Air S-Cam Brake System With ABS and ESP

Whether you're completing deliveries on busy urban streets or driving on highways, the Ultra T.6’s performance stands as a testament to its efficiency, power, and reliability.

Contact Us

Features designed for performance and profits

3.3L NG Common Rail TCIC Euro-IV

Advantage

1. Most Efficient Engine with 3300 cc capacity
2. Higher Mileage
3. High 155Ps Power
4. Common Rail FIP with Advanced Engine Management System
5. Solenoid injectors for precise fuel delivery, superior reliability

Benefit

Move Savings due to lesser fuel consumption, Higher speed resulting in better turn around capacity

Torque of 390 Nm @ 1100-2200 rpm

Advantage

1. Best flat torque range from 1100- 2200 rpm

Benefit

Ability to pull more load easily at the low rpm ranges, Relatively less gear shifting, Better Acceleration

Dual circuit full Air S-cam Brakes + ABS + ESP

Advantage

1. Efficient and effective braking
2. Better Braking Distance
3. Decreased Response Time
4. Lesser Maintenance

Benefit

Effective and Safer braking compared to Hydraulic and air over hydraulic brakes, critical in high speed operations.

Tata G550 (6F+1R) Synchromesh Gear box with Cable shift mechanism

Advantage

1. Low Vibration
2. Improved mileage
3. Ease of Operations across terrains

Benefit

Reduced gear shifting efforts, better life of gearbox

Parabolic and semi elliptical leaf spring

Advantage

Lower maintainance cost because of less greasing,

Benefit

Better load carrying  capacity and higher driving comfort due to lower vibrations

01
ULTRA T.6

ULTRA T.6 specifications

  • Engine

    NG3.3L CR EIV

  • Engine Type

    Compression ignition, EURO-4

  • Body Type

    Cab-Chassis

  • Engine Capacity

    3300 cc

  • Max Engine Output

    125 Ps @ 2600 rpm

  • No of Cylinders

    4 INLINE

  • Cylinders / Displacement

    4 cylinder, 3300 cc

  • Max Speed

    105kmph

  • Emission

    EuroIV

  • Torque

    390 Nm at 1100-2200 rpm

  • Gradeability

    45%

  • Grade Restartability

    40%

  • Transmission Model

    Manual

  • No of Gears

    6 Forward +1 Reverse

  • Gear Box

    Tata G550 Synchromesh

  • FGR

    6.9

  • Clutch

    Single plate dry friction type, booster assisted

  • Clutch Lining Outside Diameter

    310 mm

  • Steering System

    Integrated Hydraulic Power

  • Brakes

    Dual circuit full Air S-cam Brakes + ABS + ESP

  • Brake - Front

    325 X 140 S – Cam Drum air brake

  • Brake - Rear

    325 X 140 S – Cam Drum air brake

  • Brake Drum Diameter

    325 dia

  • Suspension

    Parabolic and semi elliptical leaf spring

  • Suspension - Front

    Parabolic Springs

  • Suspension - Rear

    Semi elliptical leaf spring with auxilary springs

  • Antiroll Bar

    YES

  • No of Tyres

    Front: 2, Rear:4 and Spare: 1

  • Tyre Size

    7.5 R16 16PR

  • Wheel Rims

    6.00G X 16

  • Size & Ply rating

    7.5 R16 16PR

  • Axle - Front

    Heavy duty forged I beam

  • Axle - Rear

    Tata RA-1055

  • Axle Final ratio

    4.125

  • Frame

    Ladder Type Straight Frame

  • Frame Depth

    186

  • Frame Width

    820

  • Wheelbase

    2950

  • Ground Clearance

    191

  • Overall Length

    5311

  • Overall Width

    2050

  • Over Hang - Front

    1180

  • Over Hang - Rear

    1091

  • Turning Circle Radius

    6.5 mm

  • Turning Clearance Circle Diameter

    14.1

  • Track Front

    1565

  • Track Rear

    1620

  • Angle of Departure

    14 deg

  • GVW

    6450

  • Kerb Weight

    2800

  • Max Permissible FAW

    2800

  • Max Permissible RAW

    3650

  • Payload

    3650

  • Fuel Tank Capacity

    90

  • Cabin

    Ultra Narrow 1905mm Width

  • Cabin Ventilation

    HVAC

  • Battery

    2 x 12V 100 AH

  • Vehicle Drive

    LHD

  • Alternator

    80 Amps

  • Seats

    Driver : BUCKET TYPE + BENCH SEAT FOR 2 CO-PASSENGERS.
