Efficiency in
Every Turn

Experience the power of a true workhorse that combines practicality with performance. Designed to tackle a variety of tasks, from delivering goods to managing logistics, this truck is engineered to be your reliable partner on the road to success.

Efficiency in
Every Turn

Experience the power of a true workhorse that combines practicality with performance. Designed to tackle a variety of tasks, from delivering goods to managing logistics, this truck is engineered to be your reliable partner on the road to success.

Move ahead with the power to do more

  • <p>Emission Compliant Standard</p>

    Euro IV

    Emission Compliant Standard

  • <p>Engine Capacity</p>

    3300 cc

    Engine Capacity

  • <p>Maximum Torque</p>

    450 Nm

    Maximum Torque

  • <p>Maximum Gradeability</p>

    45%

    Maximum Gradeability

ULTRA T.7
ULTRA T.7

ULTRA T.7

The Ultra T.7 is your ultimate solution for seamless cargo transportation across a diverse range of applications. Powered by a robust compression ignition engine, this vehicle redefines performance and reliability. With an impressive maximum power output of 155 PS at 2600 rpm and a torque of 450 Nm, the Ultra T.7 is built to excel in every aspect of your cargo journey.

Navigate your cargo with precision with the Tata G550 Synchromesh 6F + 1R gearbox. It ensures smooth gear transitions and optimal control. Safety takes precedence with the advanced braking system, featuring dual-circuit full-air S-cam brakes combined with ABS and ESP, guaranteeing superior stopping power and control even in challenging terrain. The integration of parabolic and semi-elliptical leaf springs provides a cushioned ride while maintaining stability, ensuring your cargo remains secure and intact.

NG3.3L CR EIV Engine
155 Ps Maximum Power
Tata G550 6F+1R Gearbox
Dual Circuit Full Air S-Cam Brake System with ABS and ESP

Take on inclines with confidence, as the Ultra T7 boasts an exceptional gradeability of 45%. From urban streets to winding highways, this truck conquers every road with ease.


Contact Us

Features designed for performance and profits

3.3L NG Common Rail TCIC Euro-IV

Advantage

1. Most Efficient Engine with 3300 cc capacity
2. Higher Mileage
3. High 155Ps Power
4. Common Rail FIP with Advanced Engine Management System
5. Solenoid injectors for precise fuel delivery, superior reliability

Benefit

Move Savings due to lesser fuel consumption, Higher speed resulting in better turn around capacity

High Torque of 450Nm @ 1500-2000 rpm

Advantage

1. Best in class torque even at low rpm
2. Higher pulling Capacity

Benefit

Ability to pull more load easily at the low rpm ranges, Relatively less gear shifting, Better Acceleration

Dual circuit full Air S-cam Brakes + ABS + ESP

Advantage

1. Efficient and effective braking
2. Better Braking Distance
3. Decreased Response Time
4. Lesser Maintenance

Benefit

Effective and Safer braking compared to Hydraulic and air over hydraulic brakes, critical in high speed operations.

Tata G550 (6F+1R) Synchromesh Gear box with Cable shift mechanism

Advantage

1. Low Vibration
2. Improved mileage
3. Ease of Operations across terrains

Benefit

Reduced gear shifting efforts, better life of gearbox

Parabolic and semi elliptical leaf spring

Advantage

Lower maintainance cost because of less greasing,

Benefit

Better load carrying  capacity and higher driving comfort due to lower vibrations

01
ULTRA T.7

ULTRA T.7 specifications

  • Engine

    NG3.3L CR EIV

  • Engine Type

    Compression ignition, EURO-4

  • Body Type

    Cab-Chassis

  • Engine Capacity

    3300 cc

  • Max Engine Output

    155 Ps @ 2600 rpm

  • No of Cylinders

    4 INLINE

  • Cylinders / Displacement

    4 cylinder, 3300 cc

  • Max Speed

    105 kmph

  • Emission

    EuroIV

  • Torque

    450 Nm at 1500-2200 rpm

  • Gradeability

    45%

  • Grade Restartability

    40%

  • Transmission Model

    Manual

  • No of Gears

    6 Forward +1 Reverse

  • Gear Box

    Tata G550 Synchromesh

  • FGR

    6.9

  • Clutch

    Single plate dry friction type, booster assisted

  • Clutch Lining Outside Diameter

    330 mm

  • Steering System

    Integrated Hydraulic Power

  • Brakes

    Dual circuit full Air S-cam Brakes + ABS + ESP

  • Brake - Front

    325 X 140 S – Cam Drum air brake

  • Brake - Rear

    325 X 140 S – Cam Drum air brake

  • Brake Drum Diameter

    325 dia

  • Suspension

    Parabolic and semi elliptical leaf spring

  • Suspension - Front

    Parabolic Springs

  • Suspension - Rear

    Semi elliptical leaf spring with auxilary springs

  • Antiroll Bar

    YES

  • No of Tyres

    Front: 2, Rear:4 and Spare: 1

  • Tyre Size

    215/75R 17.5

  • Wheel Rims

    6.00 X 17.5

  • Size & Ply rating

    215/75R 17.5

  • Axle - Front

    Heavy duty forged I beam

  • Axle - Rear

    Tata RA-1055

  • Axle Final ratio

    4.125

  • Frame

    Ladder Type Straight Frame

  • Frame Depth

    186

  • Frame Width

    820

  • Length

    6234

  • Width

    2050

  • Height

    2457

  • Wheelbase

    3550

  • Ground Clearance

    187

  • Over Hang - Front

    1180

  • Over Hang - Rear

    1414

  • Turning Circle Radius

    6.5 mm

  • Turning Circle Diameter

    14.1

  • Track Front

    1565

  • Track Rear

    1620

  • Angle of Departure

    13 deg

  • GVW

    6450

  • Kerb Weight

    2970

  • Max Permissible FAW

    2990

  • Max Permissible RAW

    4500

  • Payload

    3480

  • Fuel Tank Capacity

    90

  • Cabin

    Ultra Narrow 1905mm Width

  • Cabin Ventilation

    HVAC

  • Battery

    2 x 12V 100 AH

  • Vehicle Drive

    LHD

  • Alternator

    80 Amps

  • Seats

    Driver : BUCKET TYPE + BENCH SEAT FOR 2 CO-PASSENGERS.
